good quality Instant Gas Water Heater Wall Mounted Gas Boiler Spirit series

Product Description

Funtion:

heating and stable domestic hot water

Dimensions:

Power 20,24,28kw:420mmx310mmx740mm

Power 32,40kw:510mmx310mmx740mm

Specification

Model

L1PB20-B1

L1PB24-B1

L1PB28-B1

L1PB32-B1

L1PB40-B1

Gas Type

Nature Gas

Natural Gas Pressure

2000Pa

Max.heating rate heat load(KW)

20

24

28

32

40

Min.heating rate heat load (KW)

8

11

12

12.8

16

DHW Rated heat load (KW)

20

24

28

32

40

Continuous hotwater production(Δt=25K)

10.0kg/min

11.6kg/min

13.5kg/min

15.5kg/min

19.5kg/min

Max. working water temp.(℃)

85℃

Heating system Max.working pressure (MPa)

0.3MPa

Power supply

220V~ 50Hz

Rate electric power

125W

125W

150W

150W

175W

Rate gas flow(m3/h)

2

2.4

2.8

3.2

4

Safety protection

1 Heating temperature limit protection

11 Leakage protection

2 Low water pressure protection

12 Swelling self-absorption

3 Water system overpressure protection

13 Automatic exhaust

4 Wind pressure protection

14 Water filters

5 Bathroom temperature limit protection

15 Overfire detection

6 Power failure reset

16 Self-recovery after gas stop

7 Flameout protection

17 Lightning protection

8 Pre-purging

18 Waterway Protection

9 Triple antifreeze protection

19 Anti-flue blockage

10 Anti-stuck water pump

20 Voltage Protection
